tcp-payload-decode-plugin

These plugins allow decoding TCP payload, in TCP content tab, to reveal their inner data.

The idea is to provide a quick and neat way to decode protocols not yet manage in real time parsing by Spider.
For communications troubleshooting, or debugging.

Signature​

function myOwnPlugin({
   inputs: {payload /* Blob */, direction /* 'out' for request | 'in' for response */},
   parameters: {},
   callbacks: {setDecodedPayload, onShowInfo, onShowError, onShowWarning },
   libs: {React, Field, Section, Payload, Divider, moment}
}){}

The plugin is called for each packetLot - a group of consecutive TCP packets with data, in the same direction -, when displaying the TCP content tab.

Inputs​

NameDescription
payloadAn HTML5 Blob object containing the merged payload of the TCP packets. In binary.
directionDirection of the communication:
- out for requests
- in for responses

Callbacks​

onShowInfo(message)​

Displays an Information toast with the message.

onShowWarning(message)​

Displays a Warning toast with the message.

onShowError(message)​

Displays an Error toast with the message.

setDecodedPayload(Element)​

Callback to return the result.
The result may be a simple test, but should be a React element, with all the complexity you may imagine 😉.

Libs​

Spider provides libs to help for display:

LibDescription
ReactReact library.
SectionA React component to display a section of information.
FieldA React component to display a couple of header + value
DividerAn horizontal divider
PayloadA rich React component to display structure Payload with pretty formatting and syntax highlighting
momentmoment-timezone lib with customized 'format' method to take active timezone into account

See existing plugins code for complete samples.

Section​

<Section
    title={'Whatever string or React element'}
    explain={`Long text of React element to display when clicking on a (i) icon`}
>
    {/* any children elements */}
</Section>

Field​

<Field header={'Name of the field'}>
    {/* Any value */}
</Field>

Divider​

<Divider/>

Payload​

<Payload
    payload={/* String containing the structure payload */}
    language={'json|xml|css|html'}
/>

Output​

Output must be sent:

  • Using setDecodedPayload callback

Examples​

HTTP decoder​

Decodes HTTP messages. Extract payload type from content-type header.

Parameters​

N/A

Output​

HTTP Decoder.png

Code​

The plugin code is freely available here: https://gitlab.com/spider-analyzer/plugins/http-decoder

MQTT decoder​

Decodes MQTT messages. Up to v4.
Supports JSON payload.

Parameters​

N/A

Output​

MQTT Decoder.png

Code​

The plugin code is freely available here: https://gitlab.com/spider-analyzer/plugins/mqtt-decoder

Redis decoder​

Decodes Redis messages.
Supports JSON payload.

Parameters​

N/A

Output​

Redis Decoder.png

Code​

The plugin code is freely available here: https://gitlab.com/spider-analyzer/plugins/redis-decoder
